EXC-JH11B

An extremely energy-efficient, eye-care new product that can replace the traditional light source chalkboard light;
Its professional appearance and structural design maximizes the optimization of the product's heat dissipation performance and ensures the long service life of the product;
The use of high luminous efficiency, full spectrum SMD2835 light source, professional lens design, making the lamps and lanterns out of the light more soft, more uniform, with a similar spectrum to the sunlight.
With a spectrum similar to the sun's light on the student's eyes more meticulous care, slowing down visual fatigue;
Unique three-row lens design, plus optical grille anti-glare, effectively ensure the light uniformity and eliminate the glare brought about by the trouble;
Built-in constant-current drive power supply, taking up little space, easy to install and use, and to ensure that the lamps and lanterns instantly lit without flicker.

Basic Specifications

Voltage：AC220-240V
Power：36W
Power factor：≥0.95
Color rendering index (CRI)：Ra＞95，R9>90，full-spectrum LED
Luminous flux：3000-3600lm
Luminous Efffcacy：>90lm/W
Blue Light Hazard：RG0
Color Tolerance：≤3 SDCM
Color：5000K/4000K/3500K
Flicker：<1%
Anti-Glare：Lamp Body Anti-Glare
Angle：C0-180 82° C90-270 25°
Blackboard Surface Uniformity：>0.86
Installation：Pendant mount
IP Rate：IP40
Material：Aluminum profile + plastic end cap
Dimensions：1230x87x80mm

Resources

Specification IES File CAD Drawing

Optional Parameters

Color

3500K

4000K

5000K

Product Silkscreen

EXC

Customized

Product Label

EXC

Customized

Clear
